Mid-sized rotary tablet press designed for high volume filling, poor flowing and sticky products as well as extreme production environments.
16 to 19 press stations for max. 44,460 tablets/hour
| Machine configurations | S 250 B/BL | ||
|---|---|---|---|
| Number of press stations | 19 | 16 | |
| Tool type | 45/54 | 50/54 | |
| Die type | 55/35 | 60/35 | |
| Die height (mm) | 35 | 35 | |
| Maximum die filling (mm) | 32 | 32 | |
| Maximum tablet diameter (mm) | 43 | 45 | |
| Maximum output* (tablets/hour) | 44,460 | 24,000 | |
| Maximum pre-compression force** (kN) | 35 | 40 | |
| Maximum main-compression force** (kN) | 100 | ||
| Standard voltage (V), frequency (Hz) | 400, 50/60 | ||
| Weight (kg) | 2,050 | ||
Datasheet (EN) 1.2 MB (pdf)
* The output depends on tablet size and compressed material.
** Maximum punch load depends on tablet design.
