Granulation process technology
Performance: 6 L to 1,120 L
Used to turn a heterogeneous fine powder mixture in a short time and with repeatability into a uniform granulation with increased particle size and higher density, offering good flow and compaction properties.
| Capacity (l) | Useful Capacity (l) | Dimensions (mm) | ||||||
|---|---|---|---|---|---|---|---|---|
| Model | min. | max. | A | B | C | D | ||
| IHT 25 | 25 | 5 | 20 | 1,415 | 2,000 | 1,330 | 775 | |
| IHT 50 | 50 | 10 | 40 | 1,720 | 2,700 | 1,840 | 1,275 | |
| IHT 100 | 100 | 20 | 80 | 1,900 | 2,875 | 2,170 | 1,515 | |
| IHT 200 | 200 | 40 | 160 | 2,010 | 2,875 | 2,450 | 1,790 | |
| IHT 300 | 300 | 60 | 240 | 2,250 | 2,990 | 2,750 | 2,100 | |
| IHT 400 | 400 | 80 | 320 | 2,650 | 3,570 | 3,060 | 2,400 | |
| IHT 600 | 600 | 120 | 480 | 2,650 | 3,550 | 3,250 | 2,600 | |
| IHT 800 | 800 | 160 | 640 | 3,000 | 3,990 | 3,500 | 3,000 | |
| IHT 1000 | 1000 | 200 | 800 | 3,100 | 4,190 | 3,750 | 3,300 | |
| IHT 1200 | 1,200 | 240 | 960 | 3,300 | 4,340 | 3,950 | 3,200 | |
| IIHT 1400 | 1,400 | 280 | 1120 | 3,600 | 4,490 | 4,150 | 3,400 | |
5.9 MB (pdf)
* Approximate data / loading levels may change depending on tablets shape and density
